Breathtech degreased medical copper pipe is designed for use in medical gas pipeline system installations and is manufactured under strict quality control procedures to ISO 9001:2008. In addition, we also provide medical copper pipe fittings include elbow, reducing elbow, street elbow, 45° elbow, straight coupling, equal tee, fitting reducer, reducing tee, and reducing couple.
Specifications
Adopting continuous casting and rolling production process, high purity, fine structure, and low oxygen content. No porosity, trachoma, loose, good thermal conductivity, processability, ductility, corrosion resistance, and weather resistance. Easy to solder and braze. The product quality is stable, the pressure is high, the elongation rate is high, and the cleanliness is high, which meets the high cleaning requirements of the fluorine-free refrigeration equipment. Straight tube plastic film winding, can be plugged, can be loaded with wooden boxes
| Model No | Explanationn | Thicknesss | Working Pressure |
| BR-C08-10 | 8 mm | 1,0 mm | 185 bar |
| BR-C10-10 | 10 mm | 1,0 mm | 148 bar |
| BR-C12-10 | 12 mm | 1,0 mm | 123 bar |
| BR-C15-10 | 15 mm | 1,0 mm | 98 bar |
| BR-C20-10 | 22 mm | 1,0 mm | 67 bar |
| BR-C22-12 | 22 mm | 1,2 mm | 80 bar |
| BR-C22-15 | 22 mm | 1,5 mm | 100 bar |
| BR-C28-10 | 28 mm | 1,0 mm | 52 bar |
| BR-C28-12 | 28 mm | 1,2 mm | 62 bar |
| BR-C28-15 | 28 mm | 1,5 mm | 79 bar |
| BR-C35-10 | 35 mm | 1,0 mm | 42 bar |
| BR-C35-12 | 35 mm | 1,2 mm | 50 bar |
| BR-C35-15 | 35 mm | 1,5 mm | 63 bar |
| BR-C42-10 | 42 mm | 1,0 mm | 35 bar |
| BR-C42-12 | 42 mm | 1,2 mm | 42 bar |
| BR-C42-15 | 42 mm | 1,5 mm | 52 bar |
| BR-C54-10 | 54 mm | 1,0 mm | 25 bar |
| BR-C54-12 | 54 mm | 1,2 mm | 32 bar |
| BR-C54-15 | 54 mm | 1,5 mm | 41 bar |
| BR-C54-20 | 54 mm | 2,0 mm | 54 bar |
| BR-C76-15 | 76 mm | 1,5 mm | 29 bar |
| BR-C76-20 | 76 mm | 2,0 mm | 39 bar |
| BR-C08-25 | 108 mm | 2,5 mm | 34 bar |
